Product Description:
The Square D 8536SBO2V03 is a 600V 3-phase motor starter with an 18 Amp rating and 3 poles. It features a 220V coil and supports horsepower ratings of 3 hp at 208V/240V and 5 hp at 480V. This nonreversing starter is part of the Class 8536 family and requires separate heater packs.
Key Features:
✔ Part Number: 8536SBO2V03
✔ Manufacturer: Square D
✔ Category: Motor Control
✔ Subcategory: Motor Starter
✔ Family: Class 8536
✔ Type: SBO
✔ Voltage: 600
✔ Amperage: 18 Amp
✔ Phase: 3
✔ Poles: 3
✔ Horse Power: HP @ 3 Phase - 208V 3 hp HP @ 3 Phase - 240V 3 hp HP @ 3 Phase - 480V 5 hp
✔ Configuration: Nonreversing
✔ Aux Contacts: No Auxiliary Contacts
✔ Coil Voltage Maximum: 240 VAC
✔ Coil Voltage Minimum: 220
✔ Nema Rating: 0
✔ Nema Starter Size: 0
✔ UPC: 785901871828
✔ GTIN: 00785901871828
✔ Country of Origin: Mexico
✔ Dimensions: 4.53 in x 6.77 in
✔ Weight: 1.84
✔ Certification: CSA, UL Listed
