Product Description:
The Square D 8536SCG3V03 is a 600V 3-phase motor starter with a 27 Amp rating and 3-pole design. It supports horsepower ratings of 7½ hp at 208V/240V and 10 hp at 480V, featuring a 220V coil. Heater packs are sold separately for customization.
Key Features:
✔ Part Number: 8536SCG3V03
✔ Manufacturer: Square D
✔ Category: Motor Control
✔ Subcategory: Motor Starter
✔ Family: Class 8536
✔ Type: SCG
✔ Voltage: 600V
✔ Amperage: 27 Amp
✔ Phase: 3
✔ Poles: 3
✔ Horsepower: 7½ hp @ 208V/240V, 10 hp @ 480V
✔ Configuration: Nonreversing
✔ Aux Contacts: No Auxiliary Contacts
✔ Coil Voltage: 220V-240V
✔ NEMA Rating: 1
✔ NEMA Starter Size: 1
✔ Enclosure: 1
✔ UPC: 785901871927
✔ GTIN: 00785901871927
✔ Country of Origin: Mexico
✔ Dimensions: 6 in x 10 in
✔ Weight: 3.34 lbs
✔ Certification: CSA, UL Listed
