Square D 8910DPA42V09 Contactor | 600V 40A 2 Pole 220V Coil Class 8910

Product Description:
The Square D 8910DPA42V09 is a Class 8910 definite purpose contactor designed for motor control applications. It operates at 600V and 40A with a 2-pole configuration, suitable for various horsepower ratings including 3 hp at 115V AC and 7.5 hp at 230V AC. This unit is equipped with a 220V AC coil and includes two normally open auxiliary contacts for enhanced control flexibility.

Key Features:
✔ Part Number: 8910DPA42V09
✔ Manufacturer: Square D
✔ Category: Motor Control
✔ Subcategory: Contactor
✔ Family: Class 8910
✔ Type: DPA
✔ Voltage: 600
✔ Amperage: 40
✔ Poles: 2
✔ Horse Power: 3 hp 115 V AC, 1 phase-7.5 hp 230 V AC, 1 phase
✔ Aux Contacts: 2 NO
✔ Coil Voltage Maximum: 220V
✔ Full Load Amps: Full Load Amps-Inductive 40A Full Load Amps-Resistive 50A
✔ Coil Voltage Minimum: 220V
✔ Frequency: 50 Hz
✔ UPC: 785901073468
✔ GTIN: 00785901073468
✔ Country of Origin: China
✔ Dimensions: 2.5 in x 4 in
✔ Weight: 1 lb
✔ Certification: CSA, RoHS, UL Listed
