Siemens B23500S01 Circuit Breaker | BL Series BL 240V 35A
Siemens B23500S01 Circuit Breaker | BL Series BL 240V 35A
Price:
Sale
Sold out
Regular price
$102.84 USD
Regular price
$485.00 USD
Sale price
$102.84 USD
Unit price
per
Shipping calculated at checkout.
Stock:
Low stock: 1 left
Couldn't load pickup availability
Product Description:
The Siemens B23500S01 is a Molded Case Circuit Breaker from the BL Series. It features a 2-pole design with a 240V, 35A rating and a 10kA@240V AIC rating. This breaker includes thermal magnetic protection and a bolt-on connection. It is compatible with Siemens P1 Panelboards and comes with a 120V shunt trip.
Key Features:
✔ Part Number: B23500S01
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: BL Series
✔ Type: BL
✔ Voltage: 240V
✔ Amperage: 35A
✔ Phase: 1
✔ Poles: 2
✔ AIC Rating: 10kA@240V
✔ Connection: Bolt-on
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 125A/BL
✔ MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu)
✔ Max. Wire Size: 6 AWG
✔ Breaker Type: Shunt Trip
✔ Protection: Thermal Magnetic
✔ Certification: CSA, HACR, UL
The Siemens B23500S01 is a Molded Case Circuit Breaker from the BL Series. It features a 2-pole design with a 240V, 35A rating and a 10kA@240V AIC rating. This breaker includes thermal magnetic protection and a bolt-on connection. It is compatible with Siemens P1 Panelboards and comes with a 120V shunt trip.
