Siemens B315HH00S01 Molded Case Circuit Breaker | 240V 15A 3P 65kA@240V Bolt-on BL Series

Product Description:
The Siemens B315HH00S01 is a Molded Case Circuit Breaker from the BL Series family. It is a 3-pole, 240V, 15A breaker with a 65kA@240V AIC rating and bolt-on connections. This model includes thermal magnetic protection and is complete with a 120V shunt trip. It is designed for use in Siemens P1 Panelboards and is HACR rated and UL listed.

Key Features:
✔ Part Number: B315HH00S01
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: BL Series
✔ Type: HBL
✔ Voltage: 240
✔ Amperage: 15
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 65kA@240V
✔ Connection: Bolt-on
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 125A/BL
✔ MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG
✔ Breaker Type: Shunt Trip
✔ Protection: Thermal Magnetic
✔ UPC: 783643269316
✔ GTIN: 00783643269316
✔ Country of Origin: Mexico
✔ Dimensions: 4 in x 4 in x 4 in
✔ Weight: 1.5
✔ Panel Type: Siemens P1 Panelboards
✔ Standards: HACR Rated, UL Listed
✔ Certification: HACR Rated, UL Listed
