Siemens B325HH00S01 Circuit Breaker | BL Series HBL 240V 25A

Product Description:
The Siemens B325HH00S01 is a Molded Case Circuit Breaker from the BL Series family. It features a 3-pole design with a 240V, 25A rating and a 65kA@240V AIC rating. This HBL-type breaker includes thermal magnetic protection and a bolt-on connection. It also comes with a 120V shunt trip for enhanced functionality.

Key Features:
✔ Part Number: B325HH00S01
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: BL Series
✔ Type: HBL
✔ Voltage: 240V
✔ Amperage: 25A
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 65kA@240V
✔ Connection: Bolt-on
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 125A/BL
✔ MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu)
✔ Max. Wire Size: 6 AWG
✔ Breaker Type: Shunt Trip
✔ Protection: Thermal Magnetic
✔ UPC: 783643529540
✔ GTIN: 00783643529540
✔ Country of Origin: Mexico
✔ Dimensions: 4.331 x 5.512 x 3.543
✔ Weight: 1.5 lbs
✔ Panel Type: Siemens P1 Panelboards
✔ Standards: HACR Rated, UL Listed
