Eaton BD1520 Circuit Breaker | 120V 20A 2P 10kA@120V Feed-Thru BD Series

Product Description:
The Eaton BD1520 is a Molded Case Circuit Breaker from the BD Series family. It is a 2-pole, 20 amp breaker rated for 120V with a 10kA@120V AIC rating. This thermal magnetic breaker uses a feed-thru connection and is suitable for Type BR Loadcenters.

Key Features:
✔ Part Number: BD1520
✔ Manufacturer: Eaton
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: BD Series
✔ Type: BD
✔ Voltage: 120
✔ Amperage: 20
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 10kA@120V
✔ Connection: Feed-Thru
✔ Functions: LI - Long-Time and Instantaneous
✔ MCM Size: Min. Wire Size 14 AWG Max. Wire Size 4 AWG
✔ Breaker Type: Tandem
✔ Protection: Thermal Magnetic
✔ UPC: 786676369107
✔ GTIN: 00786676369107
✔ Country of Origin: Dominican Republic
✔ Dimensions: 1 in x 3.2 in x 2.6 in
✔ Weight: 0.35
✔ Panel Type: Type BR Loadcenters
✔ Standards: UL 489, Federal Specifications Classification W-C375
✔ Certification: UL 489, Federal Specifications Classification W-C375
✔ Wire Size: 14 To 4 AWG (Aluminum/Copper)
