Square D BDL16020 Circuit Breaker | Powerpact BDL 600V 20A

Product Description:
The Square D BDL16020 is a Molded Case Circuit Breaker from the Powerpact family. It features a 1-pole design with a 600V, 20A rating and an AIC rating of 18kA@480V. This breaker uses a Feed-Thru connection and includes Thermal Magnetic protection for reliable performance. It is suitable for a wide range of industrial and commercial applications.

Key Features:
✔ Part Number: BDL16020
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: BDL
✔ Voltage: 600V
✔ Amperage: 20A
✔ Phase: 1
✔ Poles: 1
✔ AIC Rating: 18kA@480V
✔ Connection: Feed-Thru
✔ Functions: LI - Long-Time and Instantaneous
✔ Temp Rating: -13-158°F (-25-70°C)
✔ Certification: CSA C22.2 No 5, EN/IEC 60947-2, EN/IEC 60947-5-1, GB 14048.2, NEMA AB1, NMX J-266, UL 489
✔ UPC: 606481148462
✔ GTIN: 03606480000000
✔ Country of Origin: Mexico
✔ Dimensions: 1.06 in x 5.39 in
✔ Weight: 675.9 g
✔ Wire Size: AWG 6...AWG 2/0 fine stranded aluminum/copper
AWG 14...AWG 3/0 rigid or stranded aluminum/copper
