Square D BGA36025 Circuit Breaker | 600V 25A 3P 35kA@480V I-Line Plug-In Powerpact

Product Description:
The Square D BGA36025 is a Molded Case Circuit Breaker from the Powerpact family. It is a 3-pole, 25 amp breaker rated for 600 Volts with an AIC rating of 35kA at 480V. This model features an I-Line Style Plug-In connection and provides Thermal Magnetic protection for reliable circuit interruption.

Key Features:
✔ Part Number: BGA36025
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: BGA
✔ Voltage: 600
✔ Amperage: 25
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 35kA@480V
✔ Connection: I-Line Style Plug-In
✔ Protection: Thermal Magnetic
✔ Frame Size: 125A/BG
✔ Wire Size: AWG 14...AWG 2/0 aluminum/copper
✔ Certification: CSA C22.2 No 5, EN/IEC 60947-2, EN/IEC 60947-5-1, GB 14048.2, NEMA AB1, NMX J-266, UL 489
✔ UPC: 785901022770
✔ GTIN: 03606481153692
✔ Country of Origin: Mexico
