Siemens BQ2H020 Circuit Breaker | 240V 20A 2 Pole 10kA@240V Bolt-on BQ Series

Product Description:
The Siemens BQ2H020 is a Molded Case Circuit Breaker from the BQ Series family. It is a 2-pole, 240 Volt, 20 amp rated breaker with a 10kA@240V AIC rating and uses a bolt-on connection. This circuit breaker provides thermal magnetic protection for reliable performance.

Key Features:
✔ Part Number: BQ2H020
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: BQ Series
✔ Type: BQ
✔ Voltage: 240
✔ Amperage: 20
✔ Poles: 2
✔ AIC rating: 10kA@240V
✔ Connection: Bolt-on
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 125A/BQH
✔ MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 10 AWG
✔ Breaker Type: Standard
✔ Protection: Thermal Magnetic
✔ UPC: 783643102507
✔ GTIN: 00783643102507
✔ Country of Origin: Mexico
✔ Dimensions: 2 in x 4 in x 4 in
✔ Weight: 0.71
✔ Panel Type: Siemens Panelboards
✔ Standards: HACR Rated, UL Listed
✔ Certification: HACR Rated, UL Listed
