Siemens BQ3B03000S01 Molded Case Circuit Breaker | 240V 30A 3P 10kA@240V Bolt-on BQ Series

Product Description:
The Siemens BQ3B03000S01 is a 3-pole molded case circuit breaker with a 30 amp rating and 240V capacity. It features thermal magnetic protection and a bolt-on connection for secure installation. This breaker has an AIC rating of 10kA@240V and includes a non-interchangeable 120V shunt trip. It is designed for use in Siemens panelboards and meets UL standards.

Key Features:
✔ Part Number: BQ3B03000S01
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: BQ Series
✔ Type: BQ
✔ Voltage: 240
✔ Amperage: 30
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 10kA@240V
✔ Connection: Bolt-on
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 125A/BQ
✔ MCM Size: Min. Wire Size 8 AWG Max. Wire Size 4 AWG (Al), 6 AWG (Cu)
✔ Breaker Type: Shunt Trip
✔ Protection: Thermal Magnetic
✔ UPC: 783643237834
✔ GTIN: 00783643237834
✔ Country of Origin: Mexico
✔ Dimensions: 3.937 x 5.906 x 3.937
✔ Weight: 1
✔ Panel Type: Siemens Panelboards
✔ Standards: HACR Rated, UL Listed
✔ Certification: UL Listed
