Product Description:
The Cutler Hammer C25BNB225T is a 600V 1-phase 25A 2-pole contactor with a 24V coil. It is designed for motor control applications and features a non-reversing configuration. This definite purpose contactor includes a 277 VAC coil and is suitable for both inductive and resistive loads.
Key Features:
✔ Part Number: C25BNB225T
✔ Manufacturer: Cutler Hammer
✔ Category: Motor Control
✔ Subcategory: Contactor
✔ Family: C25 Series
✔ Type: C25
✔ Voltage: 600
✔ Amperage: 25
✔ Phase: 1
✔ Poles: 2
✔ Configuration: Non-Reversing
✔ Coil Voltage Maximum: 24
✔ Full Load Amps: Full Load Amps-Inductive 25A Full Load Amps-Resistive 30A
✔ Coil Voltage Minimum: 24
✔ Frequency: 60 Hz
✔ UPC: 78668511601
✔ GTIN: 00786685116013
✔ Country of Origin: China
✔ Dimensions: 1.97 in x 3.19 in
✔ Weight: 1
✔ Certification: CSA, RoHS, UL Listed
