Cutler Hammer C25DNF240T Contactor 2 pole 1 phase 600V 40A 24V coil C25 Series

Product Description:
The Cutler Hammer C25DNF240T is a definite purpose contactor designed for motor control applications. It operates at 600V with a 40A rating and features a 24V coil for reliable switching. This 2-pole, non-reversing contactor is built for single-phase systems and is compatible with a range of motor frames. It is CSA certified and UL recognized for safety and performance.

Key Features:
✔ Part Number: C25DNF240T
✔ Manufacturer: Cutler Hammer
✔ Category: Motor Control
✔ Subcategory: Contactor
✔ Family: C25 Series
✔ Type: C25
✔ Voltage: 600
✔ Amperage: 40
✔ Phase: 1
✔ Poles: 2
✔ Configuration: Non-Reversing
✔ Coil Voltage Maximum: 24
✔ Coil Voltage Minimum: 24
✔ Compatible Frames: LDB,LD,HLD,LDC,CLD,CHLD,CLDC,MDL,HMDL,MDLB,HMDLB
✔ Frequency: 50 Hz
✔ UPC: 782116300426
✔ GTIN: 00782116300426
✔ Country of Origin: China
✔ Dimensions: 3.75 in x 3.35 in x 2.4 in (Height x Length x Width)
✔ Weight: 2.20462 lb
✔ Certification: CSA Certified UL Recognized UL Listed file E1491 (Guide Number NLDX2)
