Product Description:
The Cutler Hammer CCVH2175 is a Molded Case Circuit Breaker from the Tenant Main family. This 2-pole breaker operates at 240V with a 175A rating and 25kA@240V AIC rating. It features Feed-Thru connections and Thermal Magnetic protection for reliable performance.
Key Features:
✔ Part Number: CCVH2175
✔ Manufacturer: Cutler Hammer
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Tenant Main
✔ Type: CCVH
✔ Voltage: 240
✔ Amperage: 175
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 25kA@240V
✔ Connection: Feed-Thru
✔ Functions: LI - Long-Time and Instantaneous
✔ Protection: Thermal Magnetic
✔ UPC: 786685368542
✔ GTIN: 00786685368542
✔ Country of Origin: Dominican Republic
✔ Dimensions: Length 30.68in Height 62.18in Width 31.44in
✔ Weight: 2
✔ Certification: UL 489
✔ Wire Size: #2/0 AWG to 300KCmil CU/AL
