Product Description:
The CD225N is a Square D Series E general duty safety switch designed for single-phase applications. It features a NEMA 1 enclosure, fusible type design, and accepts H, K, J, and R fuses. With a 400A rating and 100kA@240V maximum interrupting capacity, it provides reliable circuit protection. Ideal for industrial and commercial electrical systems.
Key Features:
✔ Part Number: CD225N
✔ Manufacturer: Square D
✔ Category: Switch
✔ Subcategory: Disconnect
✔ Voltage: 240
✔ Amperage: 400
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 100kA@240V
✔ Fuse Class: H,K,J,R
✔ Configuration: Single
✔ Switch Style: Fusible
✔ Nema Rating: NEMA 1
✔ Compatible Frames: RGF
✔ UPC: 785901182009
✔ GTIN: 00785901000000
✔ Country of Origin: Mexico
✔ Dimensions: 24.88 in x 8.88 in x 45.12 in (WxDxH)
✔ Weight: 48.08
✔ Certification: CSA
