Eaton CH120 Circuit Breaker | 120V 20A 1P 10kA@120V Plug-In CH Series

Product Description:
The Eaton CH120 is a Molded Case Circuit Breaker from the CH Series family. It features a 1-pole design with a 120V, 20A rating and a 10kA@120V AIC rating. This breaker uses a Plug-In connection and offers Thermal Magnetic protection for reliable performance.

Key Features:
✔ Part Number: CH120
✔ Manufacturer: Cutler Hammer
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: CH Series
✔ Type: CH
✔ Voltage: 120
✔ Amperage: 20
✔ Phase: 1
✔ Poles: 1
✔ AIC rating: 10kA@120V
✔ Connection: Plug-In
✔ Functions: LI - Long-Time and Instantaneous
✔ MCM Size: Min. Wire Size (2) 14 AWG (Cu/Al) Max. Wire Size (2) 10 AWG (Cu/Al)
✔ Breaker Type: CH
✔ Protection: Thermal Magnetic
✔ UPC: 782113101644
✔ GTIN: 00782113101644
✔ Country of Origin: United States
✔ Dimensions: Length 3.5in Height 3in Width 5in
✔ Weight: 1.26
✔ Panel Type: Type CH Loadcenters
✔ Standards: UL 489
✔ Certification: UL 489
✔ Wire Size: (1) 14-8 AWG (2) 14-10 AWG (Aluminum/Copper)
