Product Description:
The Cutler Hammer CHF240ST is a Molded Case Circuit Breaker from the CH Series family. It features a 2-pole design with a 240V, 40A rating and a 10kA@240V AIC rating. This breaker uses a Plug-In connection and offers Thermal Magnetic protection for reliable performance.
Key Features:
✔ Part Number: CHF240ST
✔ Manufacturer: Cutler Hammer
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: CH Series
✔ Type: CH
✔ Voltage: 240
✔ Amperage: 40
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 10kA@240V
✔ Connection: Plug-In
✔ Protection: Thermal Magnetic
✔ UPC: 786685708409
✔ GTIN: 00786685708409
✔ Country of Origin: Dominican Republic
✔ Dimensions: Length 5.875in, Height 8in, Width 3.875in
✔ Weight: 0.75
✔ Certification: UL Listed, UL 489, HACR Rated
✔ Wire Size: 14 to 2 AWG, CU/AL
