Siemens ED22B025 Circuit Breaker | 240V 25A 2P 10kA@240V Bolt-On Sentron Series

Product Description:
The Siemens ED22B025 is a Molded Case Circuit Breaker from the Sentron Series family. It is a 2-pole, 25 amp breaker rated for 240 volts with an AIC rating of 10kA@240V. This thermal magnetic circuit breaker uses a bolt-on connection for secure installation.

Key Features:
✔ Part Number: ED22B025
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Sentron Series
✔ Type: ED
✔ Voltage: 240
✔ Amperage: 25
✔ Poles: 2
✔ AIC rating: 10kA@240V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Load Side Lug
✔ Frame Size: 125A/ED
✔ MCM Size: Min. Wire Size 10 AWG Max. Wire Size 1/0 AWG
✔ Protection: Thermal Magnetic
✔ Phase Connection: Any
✔ UPC: 783643208858
✔ GTIN: 00783643208858
✔ Country of Origin: United States
✔ Dimensions: 2 in x 6.34 in
✔ Panel Type: SB Switchboards, Sentron Panelboards
✔ Standards: HACR Rated, UL Listed
✔ Certification: HACR Rated, UL Listed
✔ Wire Size: 12 To 10 AWG (Aluminum)
