Cutler Hammer ED3100 Circuit Breaker | 240V 100A 3P 65kA@240V Lug In Panelboard Series C

Product Description:
The Cutler Hammer ED3100 is a Molded Case Circuit Breaker from the Series C family. It is a 3-pole, 100 amp breaker rated for 240 Volts with an AIC rating of 65kA@240V. This circuit breaker features Thermal Magnetic protection and uses a Lug In Panelboard connection for reliable performance.

Key Features:
✔ Part Number: ED3100
✔ Manufacturer: Cutler Hammer
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Series C
✔ Type: ED
✔ Voltage: 240
✔ Amperage: 100
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 65kA@240V
✔ Connection: Lug In Panelboard
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Load Side Lug
✔ Frame Size: 225A/F
✔ MCM Size: Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
✔ Breaker Type: Standard
✔ Protection: Thermal Magnetic
✔ Phase Connection: ABC
✔ UPC: 786679455388
✔ GTIN: 00786679455388
✔ Country of Origin: Dominican Republic
✔ Dimensions: 4.13 in x 3.38 in
✔ Weight: 4.5
✔ Panel Type: Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
✔ Standards: CSA Certified, IEC Rated, UL Listed
✔ Certification: CSA Certified, IEC Rated, UL Listed
