Square D EDB24020SA Circuit Breaker | 480Y/277V 20A 2P 18kA@480V Bolt-on EDB Series

Product Description:
The Square D EDB24020SA is a molded case circuit breaker designed for reliable electrical protection. It is rated for 480Y/277 volts and 20 amps, with an interrupting capacity of 18kA at 480V. This 2-pole breaker features thermal magnetic protection and a bolt-on connection for secure installation. It also includes a 120V shunt trip function for added control.

Key Features:
✔ Part Number: EDB24020SA
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: EDB Series
✔ Type: EDB
✔ Voltage: 480Y/277
✔ Amperage: 20
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 18kA@480V
✔ Connection: Bolt-on
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 125A/EDB
✔ MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG
✔ Breaker Type: Shunt Trip
✔ Protection: Thermal Magnetic
✔ UPC: 785901430797
✔ GTIN: 00785901430797
✔ Country of Origin: Mexico
✔ Dimensions: 2.94 in x 5.66 in x 5.66 in
✔ Weight: 1.44
✔ Panel Type: Square D NF Panelboards
✔ Standards: cULus
✔ Certification: cULus
