Square D EDB34020LH Circuit Breaker | 480V 20A 3P 18kA@480V Bolt-On EDB Series

Product Description:
The Square D EDB34020LH is a Molded Case Circuit Breaker from the EDB Series. It features a 3-pole design with a 480V voltage rating and 20A amperage capacity. This breaker offers Thermal Magnetic protection and has an AIC rating of 18kA@480V. It uses a Bolt-On connection for secure installation.

Key Features:
✔ Part Number: EDB34020LH
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: EDB Series
✔ Voltage: 480
✔ Amperage: 20
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 18kA@480V
✔ Connection: Bolt-On
✔ Protection: Thermal Magnetic
✔ UPC: 785901638582
✔ GTIN: 00785901638582
✔ Country of Origin: Mexico
✔ Dimensions: Height 5.66 in (143.76 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Weight: 1.58
✔ Panel Type: NF panelboard
✔ Certification: cULus
✔ Wire Size: AWG 12...AWG 2/0 aluminum, AWG 14...AWG 2/0 copper
