Square D EDB34125AABASA Molded Case Circuit Breaker | 480V 125A 3P 18kA@480V Bolt-On EDB Series

Product Description:
The Square D EDB34125AABASA is a Molded Case Circuit Breaker from the EDB Series. It features a 3-pole design with a 480V voltage rating and 125 amp capacity, offering an AIC rating of 18kA@480V. This circuit breaker includes Thermal Magnetic protection and a Bolt-On connection for secure installation. It comes complete with an auxiliary switch, alarm switch, and shunt trip package.

Key Features:
✔ Part Number: EDB34125AABASA
✔ Manufacturer: Schneider Electric||Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: EDB Series
✔ Type: EDB
✔ Voltage: 480
✔ Amperage: 125
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 18kA@480V
✔ Connection: Bolt-On
✔ Protection: Thermal Magnetic
✔ UPC: 785901950202
✔ GTIN: 00785901950202
✔ Dimensions: Height 5.66 in (143.76 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Weight: 1.9
✔ Panel Type: NF panelboard
✔ Certification: cULus
✔ Wire Size: AWG 12...AWG 2/0 aluminum, AWG 14...AWG 2/0 copper
