Square D EDB36030 Circuit Breaker | 600V 30A 3P 18kA@480V Bolt-On EDB Series

Product Description:
The Square D EDB36030 is a 3-pole molded case circuit breaker designed for reliable electrical protection. It is rated for 600 Volts and 30 Amps, with an interrupting capacity of 18kA at 480V. This breaker features thermal magnetic protection and a bolt-on connection for secure installation.

Key Features:
✔ Part Number: EDB36030
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: EDB Series
✔ Type: EDB
✔ Voltage: 600
✔ Amperage: 30
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 18kA@480V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: D; E-Frame
✔ MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 2/0 AWG (Cu/Al)
✔ Protection: Thermal Magnetic
✔ UPC: 785901233961
✔ GTIN: 00785901233961
✔ Country of Origin: Mexico
✔ Dimensions: 2.94 in x 5.66 in
✔ Weight: 1.68
✔ Panel Type: NF panelboard
✔ Standards: cULus
✔ Certification: cULus
✔ Wire Size: AWG 12...AWG 6 aluminum, AWG 14...AWG 6 copper
