Square D EDB36070 Molded Case Circuit Breaker | 600V 70A 3P 18kA@480V Bolt-On EDB Series

Product Description:
The Square D EDB36070 is a 3-pole molded case circuit breaker rated for 70 amps and 600 volts. It features thermal magnetic protection and a bolt-on connection type. This circuit breaker is part of the EDB Series and is suitable for use in various electrical distribution applications.

Key Features:
✔ Part Number: EDB36070
✔ Manufacturer: Schneider Electric, Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: EDB Series
✔ Type: EDB
✔ Voltage: 600
✔ Amperage: 70
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 18kA@480V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: D; E-Frame
✔ MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 2/0 AWG (Cu/Al)
✔ Protection: Thermal Magnetic
✔ UPC: 785901407010
✔ GTIN: 00785901407010
✔ Country of Origin: Mexico
✔ Dimensions: 2.94 in x 5.66 in
✔ Weight: 1.61
✔ Panel Type: NF panelboard
✔ Standards: cULus
✔ Certification: cULus
✔ Wire Size: AWG 12...AWG 2/0 aluminum, AWG 14...AWG 2/0 copper
