Square D EDB36080 Circuit Breaker | 600V 80A 3P 18kA@480V Bolt-On EDB Series

Product Description:
The Square D EDB36080 is a Molded Case Circuit Breaker from the EDB Series. It features 3 poles, 600V voltage, and 80A amperage with an AIC rating of 18kA@480V. This breaker uses a Bolt-On connection and offers Thermal Magnetic protection. It is designed for industrial and commercial electrical applications.

Key Features:
✔ Part Number: EDB36080
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: EDB Series
✔ Type: EDB
✔ Voltage: 600
✔ Amperage: 80
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 18kA@480V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: D; E-Frame
✔ MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 2/0 AWG (Cu/Al)
✔ Protection: Thermal Magnetic
✔ UPC: 785901235088
✔ GTIN: 00785901235088
✔ Country of Origin: Mexico
✔ Dimensions: 2.94 in x 5.66 in
✔ Weight: 1.63
✔ Panel Type: NF panelboard
✔ Standards: cULus
✔ Certification: cULus
✔ Wire Size: AWG 12...AWG 2/0 aluminum, AWG 14...AWG 2/0 copper
