Square D EGB34050SA Circuit Breaker | 480V 50A 3P 35kA@480V Bolt-on EGB Series

Product Description:
The Square D EGB34050SA is a 3-pole molded case circuit breaker with a 480V, 50A rating and 35kA@480V AIC rating. It features thermal magnetic protection and a bolt-on connection for secure installation. This breaker is part of the EGB Series and includes a 120V shunt trip. Ideal for industrial and commercial electrical systems.

Key Features:
✔ Part Number: EGB34050SA
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: EGB Series
✔ Type: EGB
✔ Voltage: 480
✔ Amperage: 50
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 35kA@480V
✔ Connection: Bolt-on
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: G; E-Frame
✔ MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 2/0 AWG (Cu/Al)
✔ Protection: Thermal Magnetic
✔ UPC: 785901159094
✔ GTIN: 00785901159094
✔ Country of Origin: Mexico
✔ Dimensions: 3.92 in x 5.66 in
✔ Weight: 1.87
✔ Panel Type: NF Panelboard
✔ Standards: cULus
✔ Certification: cULus
