Cutler Hammer EGS3030FFG Circuit Breaker | Series G EGS 600V 30A

Product Description:
The Cutler Hammer EGS3030FFG is a Molded Case Circuit Breaker from the Series G family. It features a 3-pole design with a 600V, 30A rating and a 35kA@480V AIC rating. This breaker uses a Bolt-On connection and includes Thermal Magnetic protection. It is CSA Certified, IEC Rated, and UL Listed for safety compliance.

Key Features:
✔ Part Number: EGS3030FFG
✔ Manufacturer: Cutler Hammer
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Series G
✔ Type: EGS
✔ Voltage: 600V
✔ Amperage: 30A
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 35kA@480V
✔ Connection: Bolt-On
✔ Protection: Thermal Magnetic
✔ Terminal Connection: Line/Load Lug
✔ Frame Size: 125A/EG
✔ Wire Size: 14 AWG (Min), 1/0 AWG (Max)
✔ Breaker Type: Standard
✔ Phase Connection: ABC
✔ Certification: CSA Certified, IEC Rated, UL Listed
✔ UPC: 782114877111
