Eaton EHD1030 Circuit Breaker | Series C EHD 277V 30A

Product Description:
The Eaton EHD1030 is a Molded Case Circuit Breaker from the Series C family. It features a 1-pole design with a 277V, 30A rating and a 14kA@480V AIC rating. This breaker uses a Bolt-On connection and includes Thermal Magnetic protection. It is CSA Certified, IEC Rated, and UL Listed for safety compliance.

Key Features:
✔ Part Number: EHD1030
✔ Manufacturer: Eaton
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Series C
✔ Type: EHD
✔ Voltage: 277V
✔ Amperage: 30A
✔ Phase: 1
✔ Poles: 1
✔ AIC Rating: 14kA@480V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Load Side Lug
✔ Frame Size: 100A/F
✔ MCM Size: Min. Wire Size 14 AWG, Max. Wire Size 1/0 AWG
✔ Breaker Type: Standard
✔ Protection: Thermal Magnetic
✔ Phase Connection: A
✔ Certification: CSA Certified, IEC Rated, UL Listed
✔ UPC: 786679
