Westinghouse EHD1035L Circuit Breaker | 277V 35A 1P 14kA@480V Feed-Thru Series C

Product Description:
The Westinghouse EHD1035L is a Molded Case Circuit Breaker from the Series C family. This 1-pole breaker operates at 277V with a 35A rating and 14kA@480V AIC rating. It features Feed-Thru connections and Thermal Magnetic protection for reliable performance.

Key Features:
✔ Part Number: EHD1035L
✔ Manufacturer: Westinghouse
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Series C
✔ Type: EHD
✔ Voltage: 277
✔ Amperage: 35
✔ Phase: 1
✔ Poles: 1
✔ AIC rating: 14kA@480V
✔ Connection: Feed-Thru
✔ Functions: LI - Long-Time and Instantaneous
✔ Protection: Thermal Magnetic
✔ UPC: 786679007761
✔ Weight: 2
