Westinghouse EHD1050 Circuit Breaker | Series C EHD 277V 50A

Product Description:
The Cutler Hammer EHD1050 is a Molded Case Circuit Breaker from the Series C family. It features a 1-pole design with a 277V, 50A rating and a 14kA@480V AIC rating. This breaker uses a Bolt-On connection and includes Thermal Magnetic protection. Manufactured by Westinghouse, it is suitable for various panel types and applications.

Key Features:
✔ Part Number: EHD1050
✔ Manufacturer: Westinghouse
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Series C
✔ Type: EHD
✔ Voltage: 277V
✔ Amperage: 50A
✔ Phase: 1
✔ Poles: 1
✔ AIC rating: 14kA@480V
✔ Connection: Bolt-On
✔ Protection: Thermal Magnetic
✔ Terminal Connection: Load Side Lug
✔ Frame Size: 100A/F
✔ Wire Size: Min. 14 AWG, Max. 1/0 AWG
✔ Standards: CSA Certified, IEC Rated, UL Listed
✔ Certification: CSA Certified, IEC Rated, UL Listed
✔ UPC: 786679317365
✔ GTIN: 007866793173
