Cutler Hammer EHD2035 Circuit Breaker | Series C EHD 480V 35A

Product Description:
The Cutler Hammer EHD2035 is a Molded Case Circuit Breaker from the Series C family. It is a 2-pole, 480V, 35A breaker with a 14kA@480V AIC rating and Bolt-On connection. This breaker features Thermal Magnetic protection and is suitable for various panel types.

Key Features:
✔ Part Number: EHD2035
✔ Manufacturer: Cutler Hammer
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Series C
✔ Type: EHD
✔ Voltage: 480V
✔ Amperage: 35A
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 14kA@480V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Load Side Lug
✔ Frame Size: 100A/F
✔ MCM Size: Min. Wire Size 14 AWG, Max. Wire Size 1/0 AWG
✔ Breaker Type: Standard
✔ Protection: Thermal Magnetic
✔ Phase Connection: ABC
✔ Certification: CSA Certified, IEC Rated, UL Listed
✔ UPC: 786679317457
✔ GTIN:
