Images are for reference only
Cutler Hammer
Cutler Hammer EHD3030 Circuit Breaker | Series C EHD 480V 30A
Cutler Hammer EHD3030 Circuit Breaker | Series C EHD 480V 30A
Price:
Sale
Sold out
Regular price
$336.93 USD
Regular price
$1,307.51 USD
Sale price
$336.93 USD
Unit price
per
Shipping calculated at checkout.
Stock:
41 in stock
This ships in 1-2 business days
This ships in 1-2 business days
Couldn't load pickup availability
Product Description:
The Cutler Hammer EHD3030 is a Molded Case Circuit Breaker from the Series C family. It features a 3-pole design with a 480V, 30A rating and a 14kA@480V AIC rating. This breaker uses a Bolt-On connection and includes Thermal Magnetic protection for reliable performance.
Key Features:
✔ Part Number: EHD3030
✔ Manufacturer: Cutler Hammer
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Series C
✔ Type: EHD
✔ Voltage: 480V
✔ Amperage: 30A
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 14kA@480V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Load Side Lug
✔ Frame Size: 100A/F
✔ MCM Size: Min. Wire Size 14 AWG, Max. Wire Size 1/0 AWG
✔ Breaker Type: Standard
✔ Protection: Thermal Magnetic
✔ Phase Connection: ABC
✔ Certification: CSA Certified, IEC Rated, UL Listed
✔ UPC: 786679317099
✔ GTIN:
The Cutler Hammer EHD3030 is a Molded Case Circuit Breaker from the Series C family. It features a 3-pole design with a 480V, 30A rating and a 14kA@480V AIC rating. This breaker uses a Bolt-On connection and includes Thermal Magnetic protection for reliable performance.
