Westinghouse EHD3070 Circuit Breaker | Series C EHD 480V 70A
Westinghouse EHD3070 Circuit Breaker | Series C EHD 480V 70A
Price:
Sale
Sold out
Regular price
$293.81 USD
Regular price
$1,257.31 USD
Sale price
$293.81 USD
Unit price
per
Shipping calculated at checkout.
Stock:
51 in stock
Couldn't load pickup availability
Product Description:
The Eaton EHD3070 is a Molded Case Circuit Breaker from the Series C family. It features a 3-pole design with a 480V, 70A rating and a 14kA@480V AIC rating. This Westinghouse-manufactured breaker uses a bolt-on connection and includes thermal magnetic protection.
Key Features:
✔ Part Number: EHD3070
✔ Manufacturer: Westinghouse
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Series C
✔ Type: EHD
✔ Voltage: 480V
✔ Amperage: 70A
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 14kA@480V
✔ Connection: Bolt-On
✔ Protection: Thermal Magnetic
✔ Terminal Connection: Load Side Lug
✔ Frame Size: 100A/F
✔ Wire Size: Min. 14 AWG, Max. 1/0 AWG
✔ Certification: CSA Certified, IEC Rated, UL Listed
✔ UPC: 786679317174
✔ GTIN: 00786679317174
✔ Country of Origin: Dominican Republic
