Eaton FAZ-C15/2 Circuit Breaker | FAZ Series FAZ 480V 15A
Eaton FAZ-C15/2 Circuit Breaker | FAZ Series FAZ 480V 15A
Price:
Sale
Sold out
Regular price
$52.84 USD
Regular price
$240.00 USD
Sale price
$52.84 USD
Unit price
per
Shipping calculated at checkout.
Stock:
Out of stock
Couldn't load pickup availability
Product Description:
The Eaton FAZ-C15/2 is a 2-pole molded case circuit breaker from the FAZ Series. It operates at 480V with a 15A rating and a 10kA@277/480V AIC rating. This breaker features thermal magnetic protection and uses a DIN rail connection for easy installation. It is CSA, IEC, and UL certified for safety and compliance.
Key Features:
✔ Part Number: FAZ-C15/2
✔ Manufacturer: Eaton
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: FAZ Series
✔ Type: FAZ
✔ Voltage: 480V
✔ Amperage: 15A
✔ Phase: 1
✔ Poles: 2
✔ AIC Rating: 10kA@277/480V
✔ Connection: DIN Rail
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ MCM Size: Min. 18 AWG, Max. 4 AWG
✔ Protection: Thermal Magnetic
✔ UPC: 01508278759
✔ GTIN: 04015082787592
✔ Country of Origin: Romania
✔ Dimensions: 3 in x 1.38 in x 1
