Eaton FAZ-C30/1-NA-SP Circuit Breaker | FAZ Series FAZ 277V 30A

Product Description:
The Eaton FAZ-C30/1-NA-SP is a Molded Case Circuit Breaker from the FAZ Series. It features a 1-pole design with a 30A rating and 277V voltage capacity. This breaker offers 10kA AIC protection and includes thermal magnetic protection. It is compatible with Din Rail mounting and supports wire sizes from 18 AWG to 6 AWG.

Key Features:
✔ Part Number: FAZ-C30/1-NA-SP
✔ Manufacturer: Eaton
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: FAZ Series
✔ Type: FAZ
✔ Voltage: 277V
✔ Amperage: 30A
✔ Phase: 1
✔ Poles: 1
✔ AIC Rating: 10kA@277/480V
✔ Connection: Din Rail
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Screw Clamp
✔ Frame Size: 40A/FAZ
✔ MCM Size: Min. 18 AWG, Max. 6 AWG
✔ Protection: Thermal Magnetic
✔ UPC: 01508163638
✔ GTIN: 04015081636389
✔ Country of Origin: Spain
✔ Dimensions: 2.97 in x 0.7 in
✔ Weight: 1.5 lbs
✔ Standards: CSA Certified, IEC 60947-2, UL 489 Listed
✔ Certification: CSA Certified, IEC 60947-2, UL 489 Listed
