Eaton FAZ-D4/2-NA Circuit Breaker | FAZ Series FAZ-NA 480V 4A

Product Description:
The Eaton FAZ-D4/2-NA is a Molded Case Circuit Breaker from the FAZ Series. It features 2 poles, 480V voltage, and a 4A current rating with a 10kA AIC rating. This breaker includes Thermal Magnetic protection and uses a Feed-Thru connection. It is CSA Certified and UL 489 Listed for safety compliance.

Key Features:
✔ Part Number: FAZ-D4/2-NA
✔ Manufacturer: Eaton
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: FAZ Series
✔ Type: FAZ-NA
✔ Voltage: 480V
✔ Amperage: 4A
✔ Phase: 1
✔ Poles: 2
✔ AIC Rating: 10kA@277/480V
✔ Connection: Feed-Thru
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Screw Clamp
✔ Frame Size: 40A/FAZ
✔ MCM Size: Min. Wire Size 18 AWG, Max. Wire Size 6 AWG
✔ Protection: Thermal Magnetic
✔ Certification: CSA Certified, IEC 60947-2, UL 489 Listed
✔ UPC: 01508102058
✔ GTIN: 04015081020584
✔ Country of Origin: Spain
✔ Dimensions: 3 in x 1.5 in
