Eaton FAZ-D40/1-NA-SP Circuit Breaker | 20V 40A 1P 10kA@480/277V Feed-Thru FAZ Series

Product Description:
The Eaton FAZ-D40/1-NA-SP is a Molded Case Circuit Breaker from the FAZ Series family. It features a 1-pole design with a 40 amp rating and 20V voltage capacity. This breaker includes thermal magnetic protection and a Feed-Thru connection for easy installation. It meets industry standards with a 10kA@480/277V AIC rating.

Key Features:
✔ Part Number: FAZ-D40/1-NA-SP
✔ Manufacturer: Eaton
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: FAZ Series
✔ Type: FAZ
✔ Voltage: 20
✔ Amperage: 40
✔ Phase: 1
✔ Poles: 1
✔ AIC rating: 10kA@480/277V
✔ Connection: Feed-Thru
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Screw Clamp
✔ Frame Size: 40A/FAZ
✔ MCM Size: Min. Wire Size 18 AWG Max. Wire Size 6 AWG
✔ Protection: Thermal Magnetic
✔ UPC: 01508163706
✔ GTIN: 04015081637065
✔ Country of Origin: Spain
✔ Dimensions: 3 in x 1 in x
✔ Weight: 0.5
✔ Standards: CSA Certified, IEC 60947-2, UL 489 Listed
✔ Certification: CSA Certified, IEC 60947-2, UL 489 Listed
