Eaton FAZ-D7/2-NA Circuit Breaker | FAZ Series FAZ-NA 480V 7A

Product Description:
The Eaton FAZ-D7/2-NA is a 2-pole molded case circuit breaker from the FAZ Series. It operates at 480V with a 7A rating and features a 10kA AIC rating. This breaker includes thermal magnetic protection and uses a feed-thru connection. It is CSA Certified, IEC 60947-2 compliant, and UL 489 Listed.

Key Features:
✔ Part Number: FAZ-D7/2-NA
✔ Manufacturer: Eaton
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: FAZ Series
✔ Type: FAZ-NA
✔ Voltage: 480V
✔ Amperage: 7A
✔ Phase: 1
✔ Poles: 2
✔ AIC Rating: 10kA@277/480V
✔ Connection: Feed-Thru
✔ Protection: Thermal Magnetic
✔ Terminal Connection: Screw Clamp
✔ Frame Size: 40A/FAZ
✔ Wire Size: Min. 18 AWG, Max. 6 AWG
✔ Certification: CSA Certified, IEC 60947-2, UL 489 Listed
✔ UPC: 01508102061
✔ GTIN: 04015081020614
✔ Country of Origin: Spain
✔ Dimensions: 3 in x 1.5 in
✔ Weight: 2 lbs
