Cutler Hammer
Cutler Hammer FD1015 Circuit Breaker | 1P 277V 15A 35kA@277V Bolt-On Series C
Cutler Hammer FD1015 Circuit Breaker | 1P 277V 15A 35kA@277V Bolt-On Series C
Price:
Sale
Sold out
Regular price
$82.64 USD
Regular price
$823.63 USD
Sale price
$82.64 USD
Unit price
per
Shipping calculated at checkout.
Stock:
4 in stock
Limited availability. Call (855) 875-5050 to check stock. We'll confirm stock immediately after your order.
This ships in 1-2 business days
Limited availability. Call (855) 875-5050 to check stock. We'll confirm stock immediately after your order.
This ships in 1-2 business days
Couldn't load pickup availability
Product Description:
The Cutler Hammer FD1015 is a Molded Case Circuit Breaker from the Series C family. It is a 1-pole breaker rated for 277 Volts and 15 amps, with an interrupting capacity of 35kA at 277V. This thermal magnetic circuit breaker features a bolt-on connection for secure installation.
Key Features:
✔ Part Number: FD1015
✔ Manufacturer: Cutler Hammer
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Series C
✔ Type: FD
✔ Voltage: 277
✔ Amperage: 15
✔ Phase: 1
✔ Poles: 1
✔ AIC Rating: 35kA@277V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Frame Size: F Frame
✔ Protection: Thermal Magnetic
✔ UPC: 786679312100
✔ GTIN: 00786679312100
✔ Country of Origin: Dominican Republic
✔ Dimensions: Length 3.38in Height 6in Width 1.38in
✔ Weight: 4.5
✔ Certification: UL Listed
