Product Description:
The Cutler Hammer FD1100L is a Molded Case Circuit Breaker from the Series C family. It features a 1-pole design with a 277V voltage rating and 100A amperage capacity. This breaker has a 35kA@277V AIC rating and uses a Feed-Thru connection. It includes Thermal Magnetic protection for reliable performance.
Key Features:
✔ Part Number: FD1100L
✔ Manufacturer: Cutler Hammer, Eaton, Westinghouse
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Series C
✔ Type: FD
✔ Voltage: 277V
✔ Amperage: 100A
✔ Phase: 1
✔ Poles: 1
✔ AIC Rating: 35kA@277V
✔ Connection: Feed-Thru
✔ Protection: Thermal Magnetic
✔ Frame Size: F Frame
✔ Certification: UL Listed
✔ UPC: 786679398340
✔ GTIN: 00786679398340
✔ Country of Origin: Dominican Republic
✔ Dimensions: 3.38in (L) x 6in (H) x 1.38in (W)
✔ Weight: 4.5 lbs
