Cutler Hammer FD2030 Molded Case Circuit Breaker | 600V 30A 2P 35kA@480V Bolt-On Series C

Product Description:
The Cutler Hammer FD2030 is a Molded Case Circuit Breaker from the Series C family. It is a 2-pole, 30 amp breaker rated for 600 Volts with an AIC rating of 35kA@480V. This thermal magnetic circuit breaker uses a bolt-on connection for secure installation.

Key Features:
✔ Part Number: FD2030
✔ Manufacturer: Cutler Hammer
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Series C
✔ Type: FD
✔ Voltage: 600
✔ Amperage: 30
✔ Poles: 2
✔ AIC rating: 35kA@480V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Load Side Lug
✔ Frame Size: 225A/F
✔ MCM Size: Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
✔ Breaker Type: Standard
✔ Protection: Thermal Magnetic
✔ Phase Connection: AB
✔ UPC: 786679312230
✔ GTIN: 00786679312230
✔ Country of Origin: Dominican Republic
✔ Dimensions: 2.75 in x 6 in
✔ Weight: 4.5
✔ Panel Type: Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
✔ Standards: CSA Certified, IEC Rated, UL Listed
✔ Certification: CSA Certified, IEC Rated, UL Listed
