Crouse-Hinds FD3050 Circuit Breaker | 600V 50A 3P 35kA@480V Bolt-On Series C

Product Description:
The Crouse-Hinds FD3050 is a Molded Case Circuit Breaker from the Series C family. It features a 3-pole design with a 600V, 50A rating and a 35kA@480V AIC rating. This breaker uses a Bolt-On connection and offers Thermal Magnetic protection for reliable performance.

Key Features:
✔ Part Number: FD3050
✔ Manufacturer: Crouse-Hinds
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Series C
✔ Type: FD
✔ Voltage: 600
✔ Amperage: 50
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 35kA@480V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Load Side Lug
✔ Frame Size: 225A/F
✔ MCM Size: Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
✔ Breaker Type: Standard
✔ Protection: Thermal Magnetic
✔ Phase Connection: ABC
✔ UPC: 786679305690
✔ GTIN: 00786679305690
✔ Country of Origin: Dominican Republic
✔ Dimensions: 4.13 in x 6 in
✔ Weight: 4.5
✔ Panel Type: Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
✔ Standards: CSA Certified, IEC Rated, UL Listed
✔ Certification: CSA Certified, IEC Rated, UL Listed
