Square D
Square D HDA260802 Circuit Breaker | 600V 80A 2P 18kA@480V I-Line Style Plug-In Powerpact
Square D HDA260802 Circuit Breaker | 600V 80A 2P 18kA@480V I-Line Style Plug-In Powerpact
Price:
Sale
Sold out
Regular price
$786.04 USD
Regular price
$1,088.00 USD
Sale price
$786.04 USD
Unit price
per
Shipping calculated at checkout.
Stock:
Low stock: 1 left
Couldn't load pickup availability
Product Description:
The Square D HDA260802 is a Molded Case Circuit Breaker from the Powerpact family. It features a 2-pole design with a 600V, 80A rating and an 18kA@480V AIC rating. This breaker uses an I-Line Style Plug-In connection and offers Thermal Magnetic protection. It is suitable for various industrial and commercial applications.
Key Features:
✔ Part Number: HDA260802
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: HDA
✔ Voltage: 600
✔ Amperage: 80
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 18kA@480V
✔ Connection: I-Line Style Plug-In
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: I-Line, Lug
✔ Frame Size: H
✔ Wire Size: Min. 14 AWG (Cu/Al), Max. 3/0 AWG (Cu/Al)
✔ Protection: Thermal Magnetic
✔ Phase Connection: AC
✔ UPC: 785901750369
✔ GTIN: 00785901750369
✔ Country of Origin: United States
✔ Dimensions: 2.74 in x 6.4 in
✔ Weight: 1.36
✔ Standards: UL, CSA, NEMA, NOM, CE
✔ Certification: UL, CSA, NEMA, NOM, CE
