Square D HDL26045 Circuit Breaker | 600V 45A 2P 18kA@480V Bolt-On Powerpact
Square D HDL26045 Circuit Breaker | 600V 45A 2P 18kA@480V Bolt-On Powerpact
Price:
Sale
Sold out
Regular price
$495.90 USD
Regular price
$870.00 USD
Sale price
$495.90 USD
Unit price
per
Shipping calculated at checkout.
Stock:
Out of stock
Couldn't load pickup availability
Product Description:
The Square D HDL26045 is a 2-pole Molded Case Circuit Breaker from the Powerpact family, rated for 45 amps and 600 volts. It features thermal magnetic protection and a bolt-on connection for secure installation. This circuit breaker is designed for reliable performance in electrical distribution systems.
Key Features:
✔ Part Number: HDL26045
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: HDL
✔ Voltage: 600
✔ Amperage: 45
✔ Poles: 2
✔ AIC rating: 18kA@480V
✔ Connection: Bolt-On
✔ Protection: Thermal Magnetic
✔ Frame Size: H
✔ Wire Size: Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
✔ UPC: 785901630272
✔ GTIN: 00785901630272
✔ Country of Origin: United States
✔ Dimensions: 2.74 in x 6.4 in
✔ Weight: 1.38
✔ Standards: UL, CSA, NEMA, NOM, CE
✔ Certification: UL, CSA, NEMA, NOM, CE
