Square D HDL26080 Circuit Breaker | 600V 80A 2P 18kA@480V Bolt-On Powerpact

Product Description:
The Square D HDL26080 is a Molded Case Circuit Breaker from the Powerpact family. It features 2 poles, 600V voltage, and 80A amperage with an 18kA@480V AIC rating. This thermal magnetic breaker uses a bolt-on connection and is suitable for various electrical applications. It meets CE, CSA, IEC, and UL standards for safety and performance.

Key Features:
✔ Part Number: HDL26080
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: HDL
✔ Voltage: 600
✔ Amperage: 80
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 18kA@480V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Line/Load Lug
✔ Frame Size: 150A/HD
✔ Wire Size: AWG 14...AWG 3/0 aluminum/copper terminal
✔ Protection: Thermal Magnetic
✔ UPC: 785901461920
✔ GTIN: 00785901461920
✔ Country of Origin: Mexico
✔ Dimensions: 2.74 in x 6.4 in
✔ Weight: 1.38
✔ Standards: CE, CSA, IEC, UL Listed
✔ Certification: CE, CSA, IEC, UL Listed
