Square D
Square D HDL36060SA Circuit Breaker | 600V 60A 3P 18kA@480V Feed-Thru Powerpact
Square D HDL36060SA Circuit Breaker | 600V 60A 3P 18kA@480V Feed-Thru Powerpact
Price:
Sale
Sold out
Regular price
$842.16 USD
Regular price
$1,805.00 USD
Sale price
$842.16 USD
Unit price
per
Shipping calculated at checkout.
Stock:
Out of stock
Couldn't load pickup availability
Product Description:
The Square D HDL36060SA is a Powerpact family molded case circuit breaker designed for industrial and commercial electrical systems. It features a 3-pole configuration with a 600V voltage rating and 60A amperage capacity. This circuit breaker provides reliable thermal magnetic protection and includes a 110/130Vac shunt trip for enhanced control.
Key Features:
✔ Part Number: HDL36060SA
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: HDL
✔ Voltage: 600
✔ Amperage: 60
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 18kA@480V
✔ Connection: Feed-Thru
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: H
✔ MCM Size: Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
✔ Protection: Thermal Magnetic
✔ UPC: 785901590972
✔ GTIN: 00785901590972
✔ Country of Origin: United States
✔ Dimensions: 4.12 in x 6.4 in
✔ Weight: 2.27
✔ Standards: UL, CSA, NEMA, NOM, CE
✔ Certification: UL, CSA, NEMA, NOM, CE
✔ Wire Size: AWG 14...AWG 3/0 aluminum/copper terminal
The Square D HDL36060SA is a Powerpact family molded case circuit breaker designed for industrial and commercial electrical systems. It features a 3-pole configuration with a 600V voltage rating and 60A amperage capacity. This circuit breaker provides reliable thermal magnetic protection and includes a 110/130Vac shunt trip for enhanced control.
Key Features:
✔ Part Number: HDL36060SA
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: HDL
✔ Voltage: 600
✔ Amperage: 60
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 18kA@480V
✔ Connection: Feed-Thru
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: H
✔ MCM Size: Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
✔ Protection: Thermal Magnetic
✔ UPC: 785901590972
✔ GTIN: 00785901590972
✔ Country of Origin: United States
✔ Dimensions: 4.12 in x 6.4 in
✔ Weight: 2.27
✔ Standards: UL, CSA, NEMA, NOM, CE
✔ Certification: UL, CSA, NEMA, NOM, CE
✔ Wire Size: AWG 14...AWG 3/0 aluminum/copper terminal
