Square D HDL36090SA Circuit Breaker | 600V 90A 3P 18kA@480V Feed-Thru Powerpact

Product Description:
The Square D HDL36090SA is a Molded Case Circuit Breaker from the Powerpact family. It features 3 poles, 600V voltage, and 90A amperage with an 18kA@480V AIC rating. This circuit breaker uses a Feed-Thru connection and includes Thermal Magnetic protection. It comes complete with a 110/130Vac shunt trip.

Key Features:
✔ Part Number: HDL36090SA
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: HDL
✔ Voltage: 600
✔ Amperage: 90
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 18kA@480V
✔ Connection: Feed-Thru
✔ Functions: LI - Long-Time and Instantaneous
✔ Frame Size: H Frame
✔ Protection: Thermal Magnetic
✔ UPC: 785901675662
✔ GTIN: 00785901675662
✔ Dimensions: Height 6.42 in (163 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Weight: 2.27
✔ Wire Size: AWG 14...AWG 3/0 aluminum/copper terminal
