Square D HGL36150SA Circuit Breaker | 600V 150A 3P 35kA@480V Feed-Thru Powerpact
Square D HGL36150SA Circuit Breaker | 600V 150A 3P 35kA@480V Feed-Thru Powerpact
Price:
Sale
Sold out
Regular price
$0.00 USD
Regular price
$5,482.00 USD
Sale price
$0.00 USD
Unit price
per
Shipping calculated at checkout.
Stock:
Out of stock
Couldn't load pickup availability
Product Description:
The Square D HGL36150SA is a Molded Case Circuit Breaker from the Powerpact family. It features a 3-pole design with a 600V, 150A rating and 35kA@480V AIC rating. This breaker includes thermal magnetic protection and a feed-thru connection. It comes complete with a 110/130Vac shunt trip.
Key Features:
✔ Part Number: HGL36150SA
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: HGL
✔ Voltage: 600
✔ Amperage: 150
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 35kA@480V
✔ Connection: Feed-Thru
✔ Functions: LI - Long-Time and Instantaneous
✔ Frame Size: H Frame
✔ Protection: Thermal Magnetic
✔ UPC: 785901676928
✔ GTIN: 00785901676928
✔ Country of Origin: Mexico
✔ Dimensions: Height 6.42 in (163 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Weight: 1.9
✔ Wire Size: AWG 14...AWG 3/0 aluminum/copper terminal
