Siemens HHFD63B100 Circuit Breaker | 600V 100A 3P 100kA@480V Bolt-On Sentron Series

Product Description:
The Siemens HHFD63B100 is a Molded Case Circuit Breaker from the Sentron Series family. It features a 3-pole design with a 600V, 100A rating and a 100kA@480V AIC rating. This breaker uses a bolt-on connection and offers thermal magnetic protection for reliable performance. Lugs are not included and must be purchased separately.

Key Features:
✔ Part Number: HHFD63B100
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Sentron Series
✔ Type: HHFD
✔ Voltage: 600
✔ Amperage: 100
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 100kA@480V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Frame Size: FD Frame
✔ Protection: Thermal Magnetic
✔ UPC: 783643304253
✔ GTIN: 00783643304253
✔ Country of Origin: Mexico
✔ Dimensions: 5.906 x 9.843 x 6.693 (W x H x D) Inches
✔ Weight: 10
✔ Panel Type: S4, P4, SPP, F1, FC1, FCII, CDP-5, CDP-6, SB1-3, S5, P5, SPP/FPP, F2
✔ Wire Size: 6 AWG to 350 KCM (CU), 4 AWG to 350 KCM (AL)
