Cutler Hammer HMCP100R3C Molded Case Circuit Breaker | 600V 100A 3P 65kA@480V Bolt-On Series C
Cutler Hammer HMCP100R3C Molded Case Circuit Breaker | 600V 100A 3P 65kA@480V Bolt-On Series C
Price:
Sale
Sold out
Regular price
$625.85 USD
Regular price
$2,522.48 USD
Sale price
$625.85 USD
Unit price
per
Shipping calculated at checkout.
Stock:
72 in stock
Couldn't load pickup availability
Product Description:
The Cutler Hammer HMCP100R3C is a Molded Case Circuit Breaker from the Series C family. It features a 3-pole design with a 100 amp rating and 600V voltage capacity. This breaker offers Magnetic Only protection and has an AIC rating of 65kA@480V. It uses a Bolt-On connection for secure installation.
Key Features:
✔ Part Number: HMCP100R3C
✔ Manufacturer: NRI Industrial Sales LLC
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Series C
✔ Type: HMCP
✔ Voltage: 600
✔ Amperage: 100
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 65kA@480V
✔ Connection: Bolt-On
✔ Functions: I - Instantaneous
✔ Terminal Connection: Line/Load Lug
✔ Frame Size: 250A/J
✔ MCM Size: Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
✔ Breaker Type: Standard
✔ Protection: Magnetic Only
✔ Phase Connection: ABC
✔ UPC: 786679150856
✔ GTIN: 00786679150856
✔ Country of Origin: Dominican Republic
✔ Dimensions: 5 in x 5 in
✔ Weight: 4.5
✔ Panel Type: Eaton Motor Starters, Rockwell Motor Starters
✔ Standards: CSA Certified, IEC Rated, UL Listed
✔ Certification: CSA Certified, IEC Rated, UL Listed
